18-12
Cisco ONS 15454 Procedure Guide, R5.0
March 2007
Chapter 18 DLPs A100 to A199
DLP-A126 View Near-End PM Counts
Step 1 In node view, double-click the card where you want to view PM counts. The card view appears.
Step 2 Click the Performance tab.
Step 3 Click the 1 day radio button.
Step 4 Click Refresh. Performance monitoring appears in 1-day intervals synchronized with the time of day.
Step 5 View the Curr column to find PM counts for the current 1-day interval.
Each monitored performance parameter has corresponding threshold values for the current time period.
If the value of the counter exceeds the threshold value for a particular 1-day interval, a TCA is raised.
The number represents the counter value for each specific performance monitoring parameter.
Step 6 View the Prev-n columns to find PM counts for the previous 1-day intervals.
Note If a complete count over a 1-day interval is not possible, the value appears with a yellow
background. An incomplete or incorrect count can be caused by monitoring for less than
24 hours after the counter started, changing node timing settings, changing the time zone
settings, replacing a card, resetting a card, or changing port service states. When the problem is
corrected, the subsequent 1-day interval appears with a white background.
Step 7 Return to your originating procedure (NTP).
DLP-A126 View Near-End PM Counts
Step 1 In node view, double-click the card where you want to view PM counts. The card view appears.
Step 2 Click the Performance tab.
Step 3 Click the Near End radio button.
Step 4 Click Refresh. All PM parameters occurring for the selected card on the incoming signal appear. For
PM parameter definitions refer to the “Performance Monitoring” chapter of the Cisco ONS 15454
Troubleshooting Guide.
Step 5 View the Curr column to find PM counts for the current time interval.
Step 6 View the Prev-n columns to find PM counts for the previous time intervals.
Step 7 Return to your originating procedure (NTP).
Purpose This task enables you to view near-end PM counts for the selected card
and port.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
