Chapter 19 DLPs A200 to A299
DLP-A221 Provision E-Series Ethernet Ports for VLAN Membership
Step 3 For each Ethernet port, provision the following parameters:
• Port Name—If you want to label the port, type a port name.
• Mode—Choose the appropriate mode for the Ethernet port:
–
Valid choices for the E100T-12/E100T-G card are Auto, 10 Half, 10 Full, 100 Half, or 100 Full.
–
Valid choices for the E1000-2/E1000-2-G card are 1000 Full or Auto.
Note Both 1000 Full mode and Auto mode set the E1000-2 port to the 1000 Mbps and Full duplex
operating mode; however, flow control is disabled when 1000 Full is selected. Choosing
Auto mode enables the E1000-2 card to autonegotiate flow control. Flow control is a
mechanism that prevents network congestion by ensuring that transmitting devices do not
overwhelm receiving devices with data. The E1000-2 port handshakes with the connected
network device to determine if that device supports flow control.
• Enabled—Check this check box to activate the corresponding Ethernet port.
• Priority—Choose a queuing priority for the port. Options range from 0 (Low) to 7 (High). Priority
queuing (IEEE 802.1Q) reduces the impact of network congestion by mapping Ethernet traffic to
different priority levels. Refer to the priority queuing information in the Cisco ONS 15454 Reference
Manual. This parameter does not apply to an E-Series card in port-mapped mode.
• Stp Enabled—Check this check box to enable the Spanning Tree Protocol (STP) on the port. This
parameter does not apply to an E-Series card in port-mapped mode. Refer to the spanning tree
information in the Ethernet Card Software Feature and Configuration Guide for the
Cisco ONS 15454 SDH, Cisco ONS 15454, and Cisco ONS 15327.
Step 4 Click Apply.
Step 5 Repeat Steps 1 through 4 for all other cards in the VLAN, or if the E-Series card is in port-mapped mode,
repeat Steps 1 through 4 for the other card in a point-to-point circuit. Your Ethernet ports are provisioned
and ready to be configured for VLAN membership.
Step 6 Return to your originating procedure (NTP).
DLP-A221 Provision E-Series Ethernet Ports for VLAN Membership
Step 1 In node view, double-click the E-Series card graphic to open the card.
Step 2 Click the Provisioning > Ether VLAN tabs.
Purpose This task provisions E-Series ports for VLAN membership. It does not
apply to E-Series cards in port-mapped mode.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
To Next Page
