20-80
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A388 Change Line and Threshold Settings for the DS3/EC1-48 Cards
Note The threshold value appears after the circuit is created.
Step 7 Return to your originating procedure (NTP).
DLP-A388 Change Line and Threshold Settings for the DS3/EC1-48 Cards
Note EC-1 functionality is not supported in Software Release 5.0.
Step 1 Double-click the DS3/EC1-48 card where you want to change the line or threshold settings.
Step 2 Click the Provisioning tab.
Step 3 Depending on the setting you need to modify, click the Line, Line Thresholds, Elect Path Thresholds,
or SONET Thresholds tab.
Note See Chapter 7, “Manage Alarms” for information about the Alarm Profiles tab.
Table 20-7 SONET Threshold Options for the DS3XM-12 Card
Parameter Description Options
CV Coding violations Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (STS and VT Term).
ES Errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (STS and VT Term).
FC Failure count Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (STS and VT Term).
SES Severely errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (STS and VT Term).
UAS Unavailable seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (STS and VT Term).
Purpose This task changes the line and threshold settings for the DS3/EC1-48 cards.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
