9-9
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Chapter 9 Manage Circuits
NTP-A298 Reconfigure Circuits
d. (Check box visibility depends on card selection.) Click the Disable AIS on C2 Mis-Match check
box if you want to suppress the AIS when a C2 mismatch occurs.
e. Click Apply.
Note It is not necessary to set the format (16 or 64 bytes) for the circuit source expected string; the
path trace process automatically determines the format.
Step 11 After you set up the path trace, the received string appears in the Received field on the path trace setup
window. The following options are available:
• Click Hex Mode to display path trace in hexadecimal format. The button name changes to ASCII
Mode. Click it to return the path trace to ASCII format.
• Click the Reset button to reread values from the port.
• Click Default to return to the path trace default settings (Path Trace Mode is set to Off and the
New Transmit and New Expected Strings are null).
Caution Clicking Default will generate alarms if the port on the other end is provisioned with a different string.
The expect and receive strings are updated every few seconds if the Path Trace Mode field is set to Auto
or Manual.
Step 12 Click Close.
The detailed circuit window indicates path trace with an M (manual path trace) or an A (automatic path
trace) at the circuit source and destination ports.
Stop. You have completed this procedure.
NTP-A298 Reconfigure Circuits
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66. If you are already logged in, continue with
Step 2.
Step 2 Click the Circuits tab.
Step 3 Choose the circuits that you want to reconfigure.
Step 4 From the Tools menu, choose Circuits > Reconfigure Circuits.
Step 5 In the confirmation dialog box, click Yes to continue.
Purpose This procedure rebuilds circuits, which might be necessary when a large
number of circuits are in the PARTIAL status.
Tools/Equipment None
Prerequisite Procedures None
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
