18-32
Cisco ONS 15454 Procedure Guide, R5.0
March 2007
Chapter 18 DLPs A100 to A199
DLP-A166 Change Line and Threshold Settings for the DS3-12 or DS3N-12 Cards
Note The threshold value appears after the circuit is created.
Step 7 Return to your originating procedure (NTP).
DLP-A166 Change Line and Threshold Settings for the DS3-12 or DS3N-12
Cards
Step 1 Double-click the DS3-12 or DS3N-12 card where you want to change the line or threshold settings.
Step 2 Click the Provisioning tab.
Step 3 Depending on the setting you need to modify, click the Line, Line Thresholds, Elect Path Thresholds,
or SONET Thresholds tab.
Note See Chapter 7, “Manage Alarms” for information about the Alarm Behavior tab.
Step 4 Modify any of the settings found under these subtabs. For definitions of the Line settings, see Table 18-7.
For definitions of the Line Threshold settings, see Table 18-8. For definitions of the Elect Path Threshold
settings, see Table 18-9 on page 18-35. For definitions of the SONET Threshold settings, see
Table 18-10 on page 18-35.
Step 5 Click Apply.
Step 6 Repeat Steps 3 through 5 for each subtab that has parameters you want to provision.
Table 18-7 describes the values on the Provisioning > Line tabs for the DS-3 cards.
SES Severely errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near End, STS
termination).
UAS Unavailable seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near End, STS
termination).
Table 18-6 SONET Threshold Options for DS1-14 and DS1N-14 Cards (continued)
Parameter Description Options
Purpose This task changes the line and threshold settings for the DS3-12 or
DS3N-12 (DS-3) cards.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
