DLP-A434 Lock Node Security
Step 9 Click Finish.
Within the next 30 to 40 seconds, the TCC2P cards reboot. CTC switches to network view, and the CTC
Alerts dialog box appears. In network view, the node color changes to grey and a DISCONNECTED
condition appears.
Step 10 In the CTC Alerts dialog box, click Close. Wait for the reboot to finish (this might take several minutes).
Step 11 After the DISCONNECTED condition clears, complete the following steps to suppress the backplane IP
address from display in CTC and the LCD. If you do not want to suppress the backplane IP address
display, continue with Step 12.
a. Display the node in node view.
b. Click the Provisioning > Security > Data Comm tabs.
c. In the LCD IP Setting field, choose Suppress Display. This removes the IP address from display on
the ONS 15454 LCD.
d. Check the Suppress CTC IP Address check box. This removes the IP address from display in the
CTC information area and from the Provisioning > Security > Data Comm tab.
e. Click Apply.
Note After you turn on secure mode, the TCC2P IP address becomes the node IP address.
Step 12 Return to your originating procedure (NTP).
DLP-A434 Lock Node Security
Caution This task is irreversible. Do not proceed unless you want the node to permanently have two IP addresses.
Step 1 Click the Provisioning > Security > Data Comm tabs.
Step 2 Click Lock.
Step 3 In the Confirm Lock Secure Mode dialog box, click Yes .
Step 4 Return to your originating procedure (NTP).
Purpose This task locks the ONS 15454 security mode. When security mode is
locked, two IP addresses must always be provisioned for the node, one for
the TCC2P LAN (TCP/IP) port, and one for the backplane LAN port.
Tools/Equipment TCC2P cards must be installed.
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
DLP-A433 Enable Node Security Mode, page 21-11
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Superuser
