2-11
Cisco ONS 15454 Procedure Guide, R5.0
May 2006
Chapter 2 Install Cards and Fiber-Optic Cable
NTP-A274 Install the FC_MR-4 Cards
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the wristband
cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
Note If protective clips are installed on the backplane connectors of the cards, remove the clips before
installing the cards.
Note If you are installing OC-N, TXP, or MXP cards, Cisco recommends that you install these before you
install Ethernet cards.
Step 1 If you installed XC or XCVT cards review Table 2-1 on page 2-3 to determine card/slot compatibility.
If you installed XC10G cards, review Table 2-2 on page 2-5 to determine card/slot compatibility.
Step 2 Complete the “DLP-A39 Install Ethernet Cards” task on page 17-48. Allow each card to boot completely
before installing the next card.
Note If you install the wrong card in a slot, complete the “NTP-A116 Remove and Replace a Card”
procedure on page 2-17.
Step 3 Complete the “DLP-A469 Install GBIC or SFP Connectors” task on page 21-24 if you are using
E1000-2, E1000-2-G, G1000-4, or ML1000-2 cards.
Note If you need to remove a GBIC or SFP, complete the “DLP-A470 Remove GBIC or SFP
Connectors” task on page 21-26.
Step 4 Continue with the “NTP-A247 Install Fiber-Optic Cables on OC-N Cards” procedure on page 2-14.
Stop. You have completed this procedure.
NTP-A274 Install the FC_MR-4 Cards
Warning
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself.
Statement 94
Purpose This procedure installs the FC_MR-4 card, also known as the Fibre
Channel card.
Tools/Equipment FC_MR-4 card(s)
Prerequisite Procedures NTP-A15 Install the Common Control Cards, page 2-2
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
