1-2
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
Required Tools and Equipment
13. NTP-A11 Install the Rear Cover, page 1-22—Complete this procedure as needed to install the rear
cover.
14. NTP-A13 Perform the Shelf Installation Acceptance Test, page 1-30—Complete this procedure to
determine if you have correctly completed all other procedures in the chapter.
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning
This unit is intended for installation in restricted access areas. A restricted access area is where
access can only be gained by service personnel through the use of a special tool, lock and key, or
other means of security, and is controlled by the authority responsible for the location.
Statement 37
Warning
Suitable for mounting on concrete or other non-combustible surface only.
Statement 345
Warning
The covers are an integral part of the safety design of the product. Do not operate the unit without the
covers installed.
Required Tools and Equipment
You need the following tools and equipment to install and test the ONS 15454.
Cisco-Supplied Materials
The following materials are required and are shipped with the ONS 15454 shelf (wrapped in plastic).
The number in parentheses gives the quantity of the item included in the package.
• #12-24 x 3/4 pan-head Phillips mounting screws (48-1004-XX, 48-1007-XX) (8)
• #12 -24 x 3/4 socket set screws (48-1003-XX) (2)
• T-handle #12-24 hex tool for set screws (1)
• ESD wrist strap with 1.8 m (6 ft) coil cable (1)
• Tie wraps (10)
• Pinned hex (Allen) key for front door (1)
• Spacers (50-1193-XX) (4)
• Spacer mounting brackets (2)
• Clear plastic rear cover (1)
• External (bottom) brackets for the fan-tray air filter
• Shelf accessory kit (53-2329-XX ) (optional)
–
Two mounting bars (700-19701-XX)
–
Four 1-inch standoffs (50-1193-01)
