Cisco ONS 15454 Series User Manual

1-23
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A11 Install the Rear Cover
Note As needed, attach additional standoffs to the extended standoffs to meet site-specific cable
management requirements.
Step 3 Locate the mounting holes where you will install the standoffs on the EIAs you are using. Figure 1-8
shows the mounting holes on the UBIC-V. Figure 1-9 shows the mounting holes on the UBIC-H.
Figure 1-10 shows the mounting holes on the remaining EIA types (MiniBNC, SMB, etc.). You can
identify the mounting holes on all EIAs by locating the REAR COVER BRACKET LOCATION
designation.
Table 1-4 Standoffs Required for EIA Types
EIA Type
Required Standoffs for
One Extended Standoff
Total Required
Standoffs per Shelf
UBIC-V One 1 3/8-inch
Two 2-inch
Four 1 3/8-inch
Eight 2-inch
UBIC-H One 1 3/8-inch
One 2-inch
Four 1 3/8-inch
Four 2-inch
MiniBNC One 1 3/8-inch
One 2-inch
Four 1 3/8-inch
Four 2-inch
BNC One 1 3/8-inch
One 1-inch
Four 1 3/8-inch
Four 1-inch
High-Density BNC
SMB
AMP Champ

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
