DLP-A166 Change Line and Threshold Settings for the DS3-12 or DS3N-12 Cards
Table 18-9 describes the values on the Provisioning > Elect Path Thresholds tabs for the DS-3 cards.
Table 18-10 describes the values on the Provisioning > SONET Thresholds tabs for the DS-3 cards.
SES Severely errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
LOSS Loss of signal seconds; number of
one-second intervals containing one or
more LOS defects
Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
Table 18-8 Line Threshold Options for DS3-12 or DS3N-12 Cards (continued)
Parameter Description Options
Table 18-9 Electrical Path Threshold Options for DS3-12 or DS3N-12 Cards
Parameter Description Options
Port (Display only.) Port number 1 to 12
EB Errored blocks Numeric. Can be set for 15-minute or
one-day intervals, near end or far end. Select
the bullet and click Show Thresholds.
BBE Background block errors Numeric. Can be set for 15-minute or
one-day intervals, near end or far end. Select
the bullet and click Show Thresholds.
ES Errored seconds Numeric. Can be set for 15-minute or
one-day intervals, near end or far end. Select
the bullet and click Show Thresholds.
SES Severely errored seconds Numeric. Can be set for 15-minute or
one-day intervals, near end or far end. Select
the bullet and click Show Thresholds.
UAS Unavailable seconds Numeric. Can be set for 15-minute or
one-day intervals, near end or far end. Select
the bullet and click Show Thresholds.
AISS Alarm indication signal Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (DS3 Pbit: Near End
only; DS3 CPbit: Near and Far End).
Table 18-10 SONET Threshold Options for DS3-12 or DS3N-12 Cards
Parameter Description Options
Port (Display only.) DS-3 ports partitioned for
STS
Line 1, STS 1, Line 2, STS 1
Line 3, STS 1, Line 4 STS 1
CV Coding violations Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near and Far
End, STS termination only).
