Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A1 Unpack and Inspect the ONS 15454 Shelf Assembly
• Listed pressure terminal connectors such as ring and fork types; connectors must be suitable for
#10 AWG copper conductors
Tools Needed
The following tools are needed to install an ONS 15454:
• #2 Phillips screwdriver
• Medium slot-head screwdriver
• Small slot-head screwdriver
• Wire wrapper
• Wire cutters
• Wire strippers
• Crimp tool
• BNC insertion tool
Test Equipment
The following test equipment is needed to install an ONS 15454:
• Voltmeter
• Optical power meter (for use with fiber optics only)
• Bit error rate (BER) tester, DS-1 and DS-3
NTP-A1 Unpack and Inspect the ONS 15454 Shelf Assembly
Note The ONS 15454 high-density shelf (15454-SA-HD) is required if you want to use the high-density
electrical cards (48-port DS-3 and 56-port DS-1), available in a future release.
Step 1 Complete the “DLP-A1 Unpack and Verify the Shelf Assembly” task on page 17-1.
Step 2 Complete the “DLP-A2 Inspect the Shelf Assembly” task on page 17-2.
Step 3 Continue with the “NTP-A2 Install the Shelf Assembly” procedure on page 1-5.
Stop. You have completed this procedure.
Purpose This procedure unpacks the ONS 15454 and verifies the contents.
Tools/Equipment Pinned hex (Allen) key for front door
Prerequisite Procedures None
Required/As Needed Required
Onsite/Remote Onsite
Security Level None
