Chapter 2 Install Cards and Fiber-Optic Cable
NTP-A17 Install the Electrical Cards
Install higher-capacity cards first; for example, install an OC-192 card before installing an OC-48 card.
Let each card completely boot before installing the next card.
Step 2 Open the card latches/ejectors.
Step 3 Use the latches/ejectors to firmly slide the OC-N card along the guide rails until the card plugs into the
receptacle at the back of the slot.
Note If you install the wrong card in a slot, complete the “NTP-A116 Remove and Replace a Card”
procedure on page 2-17.
Step 4 Verify that the card is inserted correctly and close the latches/ejectors on the card.
Note It is possible to close the latches/ejectors when the card is not completely plugged into the
backplane. Ensure that you cannot insert the card any further.
Step 5 Verify the LED activity:
The red FAIL LED turns on for 20 to 30 seconds.
The red FAIL LED blinks for 35 to 45 seconds.
All LEDs blink once and turn off for 5 to 10 seconds.
The ACT or ACT/STBY LED becomes amber. The signal fail (SF) LED can persist until all card
ports connect to their far end counterparts and a signal is present.
Step 6 If the card does not boot up properly, or the LED activity does not mimic Step 5, check the following:
When a physical card type does not match the type of card provisioned for that slot in CTC, the card
might not boot. If an OC-N card does not boot, open CTC and ensure that the slot is not provisioned
for a different card type before assuming the card is faulty.
If the red FAIL LED does not turn on, check the power.
If you insert a card into a slot provisioned for a different card, all LEDS turn off.
If the red FAIL LED is on continuously or the LEDs behave erratically, the card is not installed
properly. Remove the card and repeat Steps 2 to 5.
Step 7 Continue with the “NTP-A247 Install Fiber-Optic Cables on OC-N Cards” procedure on page 2-14.
Stop. You have completed this procedure.
NTP-A17 Install the Electrical Cards
Purpose This procedure describes how to install electrical cards (DS-1, DS-3,
DS3XM, and EC-1).
Tools/Equipment Electrical cards
Prerequisite Procedures NTP-A15 Install the Common Control Cards, page 2-2
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
