Cisco ONS 15454 Series User Manual

2-5
Cisco ONS 15454 Procedure Guide, R5.0
May 2006
Chapter 2 Install Cards and Fiber-Optic Cable
NTP-A15 Install the Common Control Cards
Table 2-2 Card and Slot Compatibility for the XC10G Card
Slot 1234567891011121314151617
Type MS MS MS MS HS HS TCC XC AIC XC TCC HS HS MS MS MS MS
TCC2/TCC2P X X
XC10G X X
AIC X
AIC-I X
DS1-14 XXXXXX XXXXXX
DS1N-14 X
1
X
1
XX
1
X
1
X
1
X
1
X
1
X
1
XX
1
X
1
DS3-12 XXXXXX
2
X
2
XXXXX
DS3-12E XXXXXX X
2
XXXXX
DS3N-12 X
1
X
1
XX
1
X
1
X
1,2
X
1,2
X
1
X
1
XX
1
X
1
DS3N-12E X
1
X
1
XX
1
X
1
X
1,2
X
1,2
X
1
X
1
XX
1
X
1
DS3XM-6 XXXXXX
2
X
2
XXXXX
DS3XM-12 XXXXXX
2
X
2
XXXXX
DS3/EC1-48 XXX XXX
EC1-12 XXXXXX
1
XXXXXX
E100T-12 Not supported with the XC10G card.
E1000-2 Not supported with the XC10G card.
E100T-G XXXXXX XXXXXX
E1000-2-G XXXXXX XXXXXX
G1000-4 XXXXXX XXXXXX
G1K-4 XXXXXX XXXXXX
ML100-12 XXXXXX XXXXXX
ML1000-2 XXXXXX XXXXXX
OC3 IR 4/STM1
SH 1310
XXXXXX XXXXXX
OC3IR/STM1SH
1310-8
XXXX XXXX
OC12 IR STM4
SH 1310
XXXXXX XXXXXX
OC12 LR/STM4
LH 1310
XXXXXX XXXXXX
OC12 IR/STM4
SH 1310-4
XXXX XXXX
OC12 LR/STM4
LH 1550
XXXXXX XXXXXX
OC48 IR 1310 X X X X
OC48 LR 1550 X X X X

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
