A-2
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Appendix A CTC Information and Shortcuts
Display Node, Card, and Network Views
Node Icons on the Network View Map
Table A-2 lists the node icons on the network view map.
Table A-1 Change CTC Views
To display: Perform one of the following:
Node view
• Log into a node; node view is the default view.
• In network view, double-click a node icon, or right-click the node and
choose Open Node from the shortcut menu.
• In network view, single-click a node icon, then choose Go To Selected
Object View from the View menu.
• From the View menu, choose Go To Other Node, then choose the node
you want from the shortcut menu.
• Use the arrows on the CTC toolbar to navigate up or down views. For
example, in network view, click a node, then click the down arrow.
Network view
• In node view, click the up arrow or the Network View tool on the CTC
toolbar.
• From the View menu, choose Go To Network View.
Card view
• In node view, double-click a card or right-click the card and choose
Open Card.
• In node view, single-click a card icon, then choose Go To Selected Object
View from the View menu.
• Use the arrows on the CTC toolbar to navigate up or down views. For
example, in node view, click a card, then click the down arrow.
