CHAPTER
2-1
Cisco ONS 15454 Procedure Guide, R5.0
May 2006
2
Install Cards and Fiber-Optic Cable
Note The terms “Unidirectional Path Switched Ring” and “UPSR” may appear in Cisco literature. These terms
do not refer to using Cisco ONS 15xxx products in a unidirectional path switched ring configuration.
Rather, these terms, as well as “Path Protected Mesh Network” and “PPMN,” refer generally to Cisco’s
path protection feature, which may be used in any topological network configuration. Cisco does not
recommend using its path protection feature in any particular topological network configuration.
This chapter explains how to install the Cisco ONS 15454 cards and fiber-optic cable (fiber).
Before You Begin
This section lists the chapter procedures (NTPs). Turn to a procedure for applicable tasks (DLPs).
1. NTP-A15 Install the Common Control Cards, page 2-2—Complete this procedure first before
installing any other cards.
2. NTP-A16 Install the OC-N Cards, page 2-6—Complete as needed.
3. NTP-A17 Install the Electrical Cards, page 2-8—Complete as needed.
4. NTP-A246 Install Ethernet Cards and Connectors, page 2-10—Complete as needed.
5. NTP-A274 Install the FC_MR-4 Cards, page 2-11—Complete as needed.
6. NTP-A316 Install the Filler Cards, page 2-13—Complete as needed.
7. NTP-A247 Install Fiber-Optic Cables on OC-N Cards, page 2-14—Complete this procedure to
install fiber on OC-N cards, Ethernet Gigabit Interface Converters (GBICs), or small form-factor
pluggables (SFPs).
8. NTP-A245 Route Fiber-Optic Cables, page 2-17—Complete as needed.
9. NTP-A116 Remove and Replace a Card, page 2-17—Complete this procedure as needed to remove
and replace a card, including deleting the card from Cisco Transport Controller (CTC) and changing
an OC-N card without losing the card’s provisioning.
10. NTP-A20 Replace the Front Door, page 2-18—If the front door was removed, complete this
procedure to replace the front door and ground strap after installing cards and fiber.
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
