17-96
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 17 DLPs A1 to A99
DLP-A95 Provision a DS-1 Circuit Source and Destination
b. Choose CLEAR from the drop-down list.
c. Click Apply.
d. In the Confirm UPSR Switch dialog box, click Yes .
e. In the Protection Switch Result dialog box, click OK.
In the Circuits on Span window, the Switch State for all path protection circuits is CLEAR.
Step 5 Return to your originating procedure (NTP).
DLP-A95 Provision a DS-1 Circuit Source and Destination
Note After you have selected the circuit properties in the Circuit Source dialog box according to the specific
circuit creation procedure, you are ready to provision the circuit source.
Step 1 From the Node drop-down list, choose the node where the source will originate.
Step 2 From the Slot drop-down list, choose the slot containing the DS1-14, DS1N-14, DS3XM-6, or
DS3XM-12 card where the circuit will originate.
Note A VT circuit source or destination can be on the STS grooming endpoint of a portless
aggregation circuit.
Step 3 Only if you chose DS3XM-6 or DS3XM-12 as the card, choose the port from the Port drop-down list.
Step 4 From the DS-1 drop-down list, choose the source DS-1.
Step 5 If you need to create a secondary source, for example, a path protection bridge/selector circuit entry
point in a multivendor path protection, click Use Secondary Source and repeat Steps 1 through 4 to
define the secondary source. If you do not need to create a secondary source, continue with Step 6.
Step 6 Click Next.
Step 7 From the Node drop-down list, choose the destination (termination) node.
Step 8 From the Slot drop-down list, choose the slot containing the destination card. The destination is typically
a DS-1 card. You can also choose an OC-N card to map the DS-1 to a VT1.5 for OC-N transport.
Step 9 Depending on the destination card, choose the destination port, STS, VT, or DS1 from the drop-down
lists that appear based on the card selected in Step 8. See Table 6-2 on page 6-3 for a list of valid options.
CTC does not display ports, STSs, VTs, or DS1s already used by other circuits. If another user working
Purpose This task provisions an electrical circuit source and destination for a DS-1
circuit.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
