18-38
Cisco ONS 15454 Procedure Guide, R5.0
March 2007
Chapter 18 DLPs A100 to A199
DLP-A167 Change Line and Threshold Settings for the DS3-12E or DS3N-12E Cards
Table 18-12 describes the values on the Provisioning > Line Thresholds tabs for the DS3E cards.
Admin
State
Sets the port service state unless network
conditions prevent the change.
• IS—Puts the port in-service. The port
service state changes to IS-NR.
• IS,AINS—Puts the port in automatic
in-service. The port service state
changes to OOS-AU,AINS.
• OOS,DSBLD—Removes the port from
service and disables it. The port service
state changes to OOS-MA,DSBLD.
• OOS,MT—Removes the port from
service for maintenance. The port
service state changes to OOS-MA,MT.
Service
State
Identifies the autonomously generated
state that gives the overall condition of
the port. Service states appear in the
format: Primary State-Primary State
Qualifier, Secondary State.
• IS-NR—(In-Service and Normal) The
port is fully operational and performing
as provisioned.
• OOS-AU,AINS—(Out-Of-Service and
Autonomous, Automatic In-Service)
The port is out-of-service, but traffic is
carried. Alarm reporting is suppressed.
The ONS node monitors the ports for an
error-free signal. After an error-free
signal is detected, the port stays in
OOS-AU,AINS state for the duration of
the soak period. After the soak period
ends, the port service state changes to
IS-NR.
• OOS-MA,DSBLD—(Out-of-Service
and Management, Disabled) The port is
out-of-service and unable to carry
traffic.
• OOS-MA,MT—(Out-of-Service and
Management, Maintenance) The port is
out-of-service for maintenance. Alarm
reporting is suppressed, but traffic is
carried and loopbacks are allowed.
AINS Soak Sets the automatic in-service soak period.
• Duration of valid input signal, in hh.mm
format, after which the card becomes in
service (IS) automatically
• 0 to 48 hours, 15-minute increments
Table 18-11 Line Options for the DS3-12E and DS3N-12E Cards (continued)
Parameter Description Options
