20-6
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A312 Provision a Half Circuit Source and Destination on a Path Protection
Step 8 Choose the destination STS or VT from the drop-down lists that appear.
Step 9 Return to your originating procedure (NTP).
DLP-A312 Provision a Half Circuit Source and Destination on a Path Protection
Step 1 From the Node drop-down list, choose the node that will contain the half circuit.
Step 2 From the Slot drop-down list, choose the slot containing the card where the circuit will originate.
Step 3 From the Port drop-down list, choose the port where the circuit will originate. This field is not available
if a DS1 card is chosen in Step 2.
Step 4 If the circuit is a DS-1 circuit and you choose a DS1 card as the source, choose the DS-1 where the traffic
will originate from the DS1 drop-down list.
Step 5 Click Next.
Step 6 From the Node drop-down list, choose the node selected in Step 1.
Step 7 From the Slot drop-down list, choose the OC-N card that will be used to map the DS-1 to a VT1.5 for
OC-N transport or to map the DS-3 or OC-N STS circuit to an STS.
Step 8 Choose the destination STS or VT from the drop-down lists that appear.
Step 9 Click Use Secondary Destination and repeat Steps 6 through 8.
Step 10 Return to your originating procedure (NTP).
Purpose This task provisions a half circuit source and destination on path protection
configurations. A half circuit allows you to provision a partial path (one
end of a circuit), for example, if you want to provision a circuit with the
intent that the path will be completed at a later time or at a different
location.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
The Circuit Creation wizard Circuit Source page must be open.
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
