22-21
Cisco ONS 15454 Procedure Guide, R5.0
October 2005
Chapter 22 DLPs A500 to A599
DLP-A526 Change Line and Threshold Settings for the DS3i-N-12 Cards
Step 4 If you want to download a profile that is stored locally or on a network drive, click From File in the
Load Profile(s) dialog box.
a. Click Browse.
b. Navigate to the file location in the Open dialog box.
c. Click Open.
Note The Default alarm profile list contains alarm and condition severities that correspond, when
applicable, to default values established in Telcordia GR-253-CORE.
Note All default or user-defined severity settings that are CR or MJ are demoted to MN in NSA
situations as defined in Telcordia GR-474.
Step 5 Click OK.
The downloaded profile appears at the right side of the Alarm Profiles window.
Step 6 Right-click anywhere in the downloaded profile column to view the profile editing shortcut menu.
Step 7 Click Store.
Step 8 In the Store Profile(s) dialog box, click To Node( s).
a. Choose the node(s) where you want to save the profile:
• If you want to save the profile to only one node, click the node in the Node Names list.
• If you want to save the profile to all nodes, click Select All.
• If you do not want to save the profile to any nodes, click Select None.
• If you want to update alarm profile information, click Synchronize.
b. Click OK.
Step 9 Return to your originating procedure (NTP).
DLP-A526 Change Line and Threshold Settings for the DS3i-N-12 Cards
Step 1 In node view, double-click the DS3i-N-12 card where you want to change the line or threshold settings.
Step 2 Click the Provisioning tab.
Purpose This task changes the line and threshold settings for the DS3i-N-12 cards.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
