20-20
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A330 Preprovision a Slot
DLP-A330 Preprovision a Slot
Step 1 In node view, right-click the empty slot where you will later install a card.
Step 2 From the Add Card shortcut menu, choose the card type that will be installed. Only cards that can be
installed in the slot appear in the Add Card shortcut menu.
Note When you preprovision a slot, the card appears purple in the CTC shelf graphic, rather than
white when a card is installed in the slot. NP (not present) on the card graphic indicates that the
card is not physically installed.
Step 3 Return to your originating procedure (NTP).
DLP-A332 Change Tunnel Type
Step 1 From the View menu, choose Go to Network View.
Step 2 Click the Provisioning > Overhead Circuits tabs.
Step 3 Click the circuit tunnel that you want to convert.
Step 4 Click Edit.
Step 5 In the Edit circuit window, click the Tunnel tab.
Step 6 In the Attributes area, complete the following:
• If you are converting a traditional DCC tunnel to an IP-encapsulated tunnel, check the Change to
IP Tunnel check box and type the percentage of total SDCC bandwidth used in the IP tunnel (the
minimum percentage is 10 percent).
Purpose This task preprovisions a card slot in CTC before you physically install the
card in the ONS 15454.
Tools/Equipment None
Prerequisite Procedures Chapter 3, “Connect the PC and Log into the GUI”
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Purpose This task converts a traditional DCC tunnel to an IP-encapsulated tunnel or
an IP-encapsulated tunnel to a traditional DCC tunnel.
Tools/Equipment None
Prerequisite Procedures DLP-A313 Create a DCC Tunnel, page 20-7
DLP-A341 Create an IP-Encapsulated Tunnel, page 20-32
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
