DLP-A205 Clean Fiber Connectors with CLETOP
Warning Invisible laser radiation could be emitted from the end of the unterminated fiber cable or connector.
Do not stare into the beam directly with optical instruments. Viewing the laser output with certain
optical instruments (for example, eye loupes, magnifiers, and microscopes) within a distance of
100 mm could pose an eye hazard. Statement 1056
Step 1 Remove the dust cap from the fiber connector.
Step 2 Wipe the connector tip with the premoistened alcohol wipe.
Step 3 Blow-dry using filtered air.
Step 4 Use an inspection microscope to inspect each fiber connector for dirt, cracks, or scratches. If the
connector is not clean, repeat Steps 1 to 3.
Step 5 Insert the fiber connector into the applicable adapter or attach a dust cap to the fiber connector.
Note If you must replace a dust cap on a connector, first verify that the dust cap is clean. To clean the
dust cap, wipe the outside of the cap using a dry, lint-free wipe and the inside of the dust cap
using a CLETOP stick swab (14100400).
Step 6 Return to your originating procedure (NTP).
DLP-A205 Clean Fiber Connectors with CLETOP
Step 1 Remove the dust cap from the fiber connector.
Step 2 Press the lever down to open the shutter door. Each time you press the lever, you expose a clean wiping
surface.
Step 3 Insert the connector into the CLETOP cleaning cassette slot, rotate one quarter turn, and gently swipe
downwards.
Step 4 Use an inspection microscope to inspect each fiber connector for dirt, cracks, or scratches. If the
connector is not clean, repeat Steps 1 to 3.
Step 5 Insert the fiber connector into the applicable adapter or attach a dust cap to the fiber connector.
Purpose This task cleans the fiber connectors with CLETOP.
Tools/Equipment Type A Fiber Optic Connector Cleaner (CLETOP reel)
Optical receiver cleaning stick
Prerequisite Procedures None
Required/As Needed Required
Onsite/Remote Onsite
Security Level None

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
