CHAPTER
20-1
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
20
DLPs A300 to A399
Note The terms “Unidirectional Path Switched Ring” and “UPSR” may appear in Cisco literature. These terms
do not refer to using Cisco ONS 15xxx products in a unidirectional path switched ring configuration.
Rather, these terms, as well as “Path Protected Mesh Network” and “PPMN,” refer generally to Cisco’s
path protection feature, which may be used in any topological network configuration. Cisco does not
recommend using its path protection feature in any particular topological network configuration.
DLP-A300 Clear a BLSR Span Lock Out
Step 1 From the View menu, choose Go to Network View.
Step 2 Click the Provisioning > BLSR tabs.
Step 3 Choose the BLSR and click Edit.
Tip To move an icon to a new location, for example, to see BLSR channel (port) information more
clearly, you can drag and drop icons on the Edit BLSR network graphic.
Step 4 Right-click the BLSR node channel (port) where the lockout will be cleared and choose
Set West Protection Operation or Set East Protection Operation.
Step 5 In the dialog box, choose CLEAR from the drop-down list. Click OK.
Step 6 In the Confirm BLSR Operation dialog box, click Yes. The “L” that indicated the lockout disappears
from the network view map.
Step 7 From the File menu, choose Close.
Purpose This task clears a bidirectional line switched ring (BLSR) span lockout.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
