Cisco ONS 15454 Series User Manual

7-2
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Chapter 7 Manage Alarms
NTP-A195 Document Card, Node, and Network Provisioning
10. NTP-A258 Provision External Alarms and Controls on the Alarm Interface Controller-International,
page 7-11—Complete this procedure as needed to provision external alarms and controls on the
Alarm Interface Controller-International (AIC-I) card.
NTP-A195 Document Card, Node, and Network Provisioning
Step 1 Complete “DLP-A60 Log into CTC” task on page 17-66 at the node where you want to record or save
data. If you are already logged in, continue with Step 2.
Step 2 As needed, complete the “DLP-A515 Print CTC Data” task on page 22-5.
Step 3 As needed, complete the “DLP-A516 Export CTC Data” task on page 22-6.
Stop. You have completed this procedure.
NTP-A196 View Alarms, History, Events, and Conditions
Step 1 Log into the node that contains the alarms you want to view. Refer to the “DLP-A60 Log into CTC” task
on page 17-66 for instructions. If you are already logged in, continue with Step 2.
Step 2 Complete the “DLP-A390 View Alarms” task on page 20-85 as needed.
Step 3 Complete the “DLP-A517 View Alarm or Event History” task on page 22-8 as needed.
Step 4 Complete the “DLP-A111 Changing the Maximum Number of Session Entries for Alarm History” task
on page 18-1 as needed.
Purpose Use this procedure to print card, node, or network CTC information in
graphical or tabular form on a Windows-provisioned printer. This
procedure is useful for network record keeping and troubleshooting.
Tools/Equipment A printer connected to the CTC computer by a direct or network
connection
Prerequisite Procedures Chapter 4, “Turn Up Node”
Required/As needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
Purpose Use this procedure to view current or historical alarms and conditions for
a card, node, or network. This information is useful for monitoring and
troubleshooting hardware and software events.
Tools/Equipment None
Prerequisite Procedures None
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
