Page #280 background image
8-2
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Chapter 8 Monitor Performance
NTP-A253 Change the PM Display
NTP-A253 Change the PM Display
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at the node that you want to monitor. If you
are already logged in, continue with Step 2.
Step 2 In node view, double-click the electrical, Ethernet, or optical (OC-N) cards where you want to view PM
counts. The card view appears.
Step 3 As needed, use the following tasks to change the display of PM counts:
DLP-A124 Refresh PM Counts at 15-Minute Intervals, page 18-11
DLP-A125 Refresh PM Counts at One-Day Intervals, page 18-11
DLP-A347 Refresh E-Series and G-Series Ethernet PM Counts, page 20-33
DLP-A126 View Near-End PM Counts, page 18-12
DLP-A127 View Far-End PM Counts, page 18-13
DLP-A348 Monitor PM Counts for a Selected Signal, page 20-34
DLP-A129 Reset Current PM Counts, page 18-13
DLP-A349 Clear Selected PM Counts, page 20-35
DLP-A260 Set Auto-Refresh Interval for Displayed PM Counts, page 19-43
DLP-A259 Refresh Ethernet PM Counts at a Different Time Interval, page 19-42
DLP-A261 Refresh PM Counts for a Different Port, page 19-43
Stop. You have completed this procedure.
Purpose This procedure enables you to change the display of PM counts by
selecting drop-down list or radio button options in the Performance
window.
Tools/Equipment None
Prerequisite Procedures Before you monitor performance, be sure you have created the
appropriate circuits and provisioned the card according to your
specifications. For more information, see Chapter 6, “Create Circuits
and VT Tunnels” and Chapter 11, “Change Card Settings.”
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
