20-41
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A357 Create FC_MR-4 RMON Alarm Thresholds
Step 8 After the node icon becomes available (within 1 to 2 minutes), double-click it. On the shelf graphic,
observe the following:
• The previous standby TCC2/TCC2P card has a green ACT LED.
• The previous active TCC2/TCC2P card LEDs go through the following LED sequence: NP (card not
present), Ldg (software is loading), amber SBY LED (TCC2/TCC2P is in standby mode).
Step 9 Verify that traffic on the test set connected to the node is still running. If a traffic interruption occurs, do
not continue. Refer to your next level of support.
Step 10 Repeat Steps 2 through 9 to return the active/standby TCC2/TCC2P cards to their configuration at the
start of the procedure.
Step 11 Verify that the TCC2/TCC2P cards appear as noted in Step 5.
Step 12 Return to your originating procedure (NTP).
DLP-A357 Create FC_MR-4 RMON Alarm Thresholds
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at the node where you want to set up
RMON. If you are already logged in, continue with Step 2.
Step 2 Double-click the FC_MR-4 card where you want to create the RMON alarm thresholds.
Step 3 In card view, click the Provisioning > RMON Thresholds tabs.
Step 4 Click Create. The Create Threshold dialog box appears.
Step 5 From the Slot drop-down list, choose the appropriate FC_MR-4 card.
Step 6 From the Port drop-down list, choose the applicable port on the FC_MR-4 card you selected.
Step 7 From the Variable drop-down list, choose the variable. See Table 20-1 for a list of the FC_MR-4
threshold variables available in this field.
Purpose This task sets up remote monitoring (RMON) to allow network
management systems to monitor FC_MR-4 ports.
Tools/Equipment None
Prerequisite Procedures NTP-A24 Verify Card Installation, page 4-2
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Table 20-1 FC_MR-4 Threshold Variables Fibre Channel/FICON Line Rate
Mode (MIBs)
Variable Definition
iflnOctets Total number of octets received on the interface, including
framing octets.
ifInDiscards The number of inbound packets that were chosen to be discarded
even though no errors had been detected to prevent their being
deliverable to a higher-layer protocol.
