20-42
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A357 Create FC_MR-4 RMON Alarm Thresholds
iflnErrors Number of inbound packets discarded because they contain
errors.
ifOutOctets Total number of transmitted octets, including framing packets.
ifOutDiscards The number of outbound packets that were chosen to be discarded
even though no errors had been detected to prevent their being
transmitted.
txTotalPkts Total number of transmit packets.
rxTotalPkts Total number of receive packets.
fibreStatsInvalidOrderedSets Received ordered sets that are not recognized as part of the
defined Fibre Channel control words.
fibreStatsEncodingDispErrors Received control words that cannot be decoded due to invalid
disparity.
fibreStatsRxFramesTooLong Received oversize Fibre Channel frames > 2148 including cyclic
redundancy check (CRC).
fibreStatsRxFramesBadCRC Received Fibre Channel frames with bad CRC.
fibreStatsRxFrames Received total Fibre Channel frames.
fibreStatsRxOctets Received total Fibre Channel data bytes within a frame.
fibreStatsTxFramesBadCRC Transmitted Fibre Channel frames with bad CRC.
fibreStatsTxFrames Transmitted total Fibre Channel frames.
fibreStatsTxOctets Transmitted total Fibre Channel data bytes within a frame.
fibreStatsLinkResets Total number of link resets initiated by FCMR port when link
recovery port setting is enabled.
gfpStatsRxSBitErrors Received generic framing protocol (GFP) frames with single bit
errors in the core header (these errors are correctable).
gfpStatsRxMBitErrors Received GFP frames with multiple bit errors in the core header
(these errors are not correctable).
gfpStatsRxTypeInvalid Received GFP frames with invalid type (these are discarded). For
example, receiving GFP frames that contain Ethernet data when
we expect Fibre Channel data.
gfpStatsRxSblkCRCErrors Total number of superblock CRC errors with the receive
transparent GFP frame. A transparent GFP frame has multiple
superblocks, which each contain Fibre Channel data.
gfpStatsCSFRaised Number of Rx client management frames with Client Signal Fail
indication.
mediaIndStatsTxFramesTooLong Number of packets transmitted that are greater than 1548 bytes.
mediaIndStatsRxFramesTruncated Total number of frames received that are less than 5 bytes.
Table 20-1 FC_MR-4 Threshold Variables Fibre Channel/FICON Line Rate
Mode (MIBs) (continued)
Variable Definition
