Cisco ONS 15454 Series User Manual

5-27
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Chapter 5 Turn Up Network
NTP-A180 Provision a Traditional BLSR/Path Protection Dual-Ring Interconnect
Figure 5-8 Integrated Path Protection DRI Example
Stop. You have completed this procedure.
NTP-A180 Provision a Traditional BLSR/Path Protection
Dual-Ring Interconnect
Node 1
Node 3
Node 2
Node 4
Slot
5
Slot
12
Tx
Rx
Slot
5
Slot
12
Tx
Rx
Slot
6
Slot
13
Slot
5
Slot
12
Tx
Rx
Slot
5
Slot
12
Tx
Rx
Slot
6
Slot
13
Node 5 Node 6
Slot
5
Slot
12
Tx
Rx
Slot
5
Slot
12
Tx
Rx
83500
Purpose This procedure provisions a BLSR and a path protection in a traditional
DRI topology. DRIs interconnect ring topologies to provide an additional
level of protection.
Tools/Equipment None
Prerequisite Procedures NTP-A35 Verify Node Turn-Up, page 5-2
Required/As Needed As needed
Onsite/Remote Onsite
Security Level Provisioning and higher

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
