Chapter 20 DLPs A300 to A399
DLP-A387 Change Line and Threshold Settings for the DS3XM-12 Card
Table 20-6 describes the values on the Provisioning > Elect Path Thresholds tabs for the DS3XM-12
cards.
SES Severely errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds.
LOSS Loss of signal Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds.
Table 20-5 Line Thresholds Options for the DS3XM-12 Card (continued)
Parameter Description Options
Table 20-6 Electrical Path Threshold Options for the DS3XM-12 Card
Parameter Description Options
Port (Display only.) Port number 1 to 36
CV Coding violations Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
ES Errored seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
SES Severely errored seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
SAS Severely errored frame/alarm
indication signal
Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
AISS Alarm indication signal
seconds
Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
UAS Unavailable seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
