17-6
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 17 DLPs A1 to A99
DLP-A6 Mount the Shelf Assembly in a Rack (Two People)
Step 2 Ensure that the shelf assembly is set for the desired rack size (either 23 inches [584.2 mm] or 19 inches
[482.6 mm]).
Step 3 Using the hex tool that shipped with the assembly, install the two set screws into the screw holes that
will not be used to mount the shelf. Let the screws protrude sufficiently to hold the mounting bracket.
Step 4 Lift the shelf assembly to the desired rack position and set it on the set screws.
Step 5 Align the screw holes on the mounting bracket with the mounting holes in the rack.
Step 6 Using the Phillips screwdriver, install one mounting screw in each side of the assembly.
Step 7 When the shelf assembly is secured to the rack, install the remaining mounting screws.
Note Use at least one set of the horizontal screw slots on the ONS 15454 to prevent slippage.
Step 8 Using the hex tool, remove the temporary set screws.
Step 9 Return to your originating procedure (NTP).
DLP-A6 Mount the Shelf Assembly in a Rack (Two People)
Step 1 Verify that the proper fuse and alarm panel has been installed in the top mounting space. If a fuse and
alarm panel is not present, you must install one according to the manufacturer’s instructions.
• If you are installing the 15454-SA-ANSI or 15454-SA-HD shelf assembly, a 100-A fuse panel
(30-A fuse per shelf minimum) is required.
• If you are installing the 15454-SA-NEBS3 shelf assembly, a standard 80-A fuse panel (20-A fuse
per shelf minimum) is required.
Step 2 Ensure that the shelf assembly is set for the desired rack size (either 23 inches [584.2 mm] or 19 inches
[482.6 mm]).
Step 3 Using the hex tool that shipped with the shelf assembly, install the two set screws (48-1003-XX) into the
screw holes that will not be used to mount the shelf. Let the set screws protrude sufficiently to hold the
mounting brackets.
Purpose This task allows two people to mount the shelf assembly in a rack.
Tools/Equipment Pinned hex tool
Two set screws (48-1003-XX)
Eight pan-head Phillips mounting screws (48-1004-XX, 48-1007-XX)
#2 Phillips screwdriver
Prerequisite Procedures DLP-A3 Reverse the Mounting Bracket to Fit a 19-inch (482.6 mm) Rack,
page 17-2, if applicable
DLP-A4 Install the External Brackets and Air Filter, page 17-4, if
applicable
Required/As Needed Required
Onsite/Remote Onsite
Security Level None
