22-23
Cisco ONS 15454 Procedure Guide, R5.0
October 2005
Chapter 22 DLPs A500 to A599
DLP-A526 Change Line and Threshold Settings for the DS3i-N-12 Cards
Table 22-2 describes the values on the Provisioning > Line Thresholds tabs for the DS3i-N-12 cards.
Line
Length
Defines the distance (in
feet) from backplane
connection to the next
termination point.
• 0 - 225 (default)
• 226 - 450
Admin
State
Sets the port service state
unless network conditions
prevent the change.
• IS—Puts the port in service. The port service state
changes to In-Service and Normal (IS-NR).
• IS,AINS—Puts the port in automatic in-service. The
port service state changes to Out-Of-Service and
Autonomous, Automatic In-Service (OOS-AU,AINS).
• OOS,DSBLD—Removes the port from service and
disables it. The port service state changes to
Out-of-Service and Management, Disabled
(OOS-MA,DSBLD).
• OOS,MT—Removes the port from service for
maintenance. The port service state changes to
Out-of-Service and Management, Maintenance
(OOS-MA,MT).
Service
State
Identifies the
autonomously generated
state that gives the overall
condition of the port.
Service states appear in the
format: Primary
State-Primary State
Qualifier, Secondary State.
• IS-NR—The port is fully operational and performing
as provisioned.
• OOS-AU,AINS—The port is out-of-service, but traffic
is carried. Alarm reporting is suppressed. The ONS
node monitors the ports for an error-free signal. After
an error-free signal is detected, the port stays in
OOS-AU,AINS state for the duration of the soak
period. After the soak period ends, the port service
state changes to IS-NR.
• OOS-MA,DSBLD—The port is out-of-service and
unable to carry traffic.
• OOS-MA,MT—The port is out-of-service for
maintenance. Alarm reporting is suppressed, but traffic
is carried and loopbacks are allowed.
AINS Soak Sets the automatic
in-service soak period.
• Duration of valid input signal, in hh.mm format, after
which the card becomes in service (IS) automatically
• 0 to 48 hours, 15-minute increments
Table 22-1 Line Options for the DS3i-N-12 Cards (continued)
Parameter Description Options
Table 22-2 Line Threshold Options for the DS3i-N-12 Cards
Parameter Description Options
Port (Display only.) Port number 1 to 12
CV Coding violations Numeric. Can be set for 15-minute or one-day intervals.
Select the bullet and click the Show Thresholds button.
