Chapter 20 DLPs A300 to A399
DLP-A395 View BFDL PM Parameters for the DS3XM-12 Card
Note Different port and signal-type drop-down lists appear depending on the card type and the circuit
type. The appropriate types (DS1, DS3, VT path, STS path) appear based on the card. For
example, the DS3XM-12 cards list DS3, DS1, VT path, and STS path PM parameters as signal
types. This enables you to select both the DS-3 port and the DS-1 within the specified DS-3.
Step 3 From the Request drop-down list choose one of the following:
• Enhanced ES One Day—Enhanced errored seconds performance data for one day.
• Enhanced BES One Day—Enhanced bursty errored seconds performance data for one day.
• Enhanced SES One Day—Enhanced severely errored seconds performance data for one day.
• Enhanced UAS One Day—Enhanced unavailable seconds performance data for one day.
• Enhanced CSS/LOFC One Day—Enhanced controlled slip seconds and loss of frame count
performance data for one day.
Note The Request drop-down options are availableonly in DS1 ESF and BFDL modes. The
DS3XM-12 card can send requests for enhanced performance data to the far-end network
components. Enhanced performance data is displayed on CTC if the far-end network component
replies with the requested data. The normal response message will contain the current 15- minute
and current one-day PMs from Far-end for ES, UAS, BES, SES, CSS, and LOFC. If you select, for
example, Enhanced ES One Day from the Request drop-down list box, then CTC displays 96
15-minute PMs for ES and current PMs for BES, SES, UAS, CSS, and LOFC.
Step 4 In the signal type drop-down lists, choose the DS-3 port and the DS-1 port within the specified DS-3.
Step 5 Click Refresh.
Step 6 View the PM parameter names that appear in the Param column. The PM parameter values appear in the
Curr (current) and Prev-n (previous) columns. For PM parameter definitions, refer to the “Performance
Monitoring” chapter in the Cisco ONS 15454 Troubleshooting Guide.
To refresh, reset, or clear PM counts, see the “NTP-A253 Change the PM Display” procedure on
page 8-2.
Step 7 Return to your originating procedure (NTP).

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
