Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-62
021-946 EP Accessory - Service Paused By Color Mode Restriction 2-178
021-948 Insufficient Number of Subtractive Accessories 2-179
021-949 Insufficient Number of Subtractive Accessories 2-179
024
024-340 MCU Send Error Detected by Controller (invalid parameter was used) 2-180
024-341 MCU Send Error Detected by Controller (Sequence Number error) 2-180
024-342 MCU Send Error Detected by Controller (Packet Number error) 2-180
024-343 MCU Send Error Detected by Controller (Message Length error) 2-180
024-345 MCU Send Error Detected by Controller (Check Code error) 2-180
024-346 MCU Send Parity Error Detected by Controller 2-180
024-347 MCU Send Framing Error Detected by Controller 2-181
024-348 MCU Send Error Detected by Controller (Overrun error) 2-181
024-349 MCU Send Error Detected by Controller (Receive Abort error) 2-181
024-350 MCU Receive Error Detected by Controller (Sequence Number error) 2-181
024-351 MCU Receive Error Detected by Controller (Packet Number error) 2-181
024-354 MCU Receive Error Detected by Controller (Parity error) 2-181
024-356 MCU Receive Overrun Error Detected by Controller 2-181
024-359 MCU transmission receiving error detected by Controller (invalid parameter
was used)
2-181
024-360 Initialization error between IOTESS 2-181
024-361 The paper size group data is different between the ESS and the IOT. 2-182
024-362 Image Output. PAGE-SYNC occurred before video output preparation
completes.
2-183
024-363 Image Output. PAGE-SYNC completion error during video output 2-183
024-364 Image Output. DMA Transfer Error 2-184
024-365 Loopback Write Overflow -----
024-367 Other errors from Decompress (Extension) 2-184
024-368 Image Output. PCI Bus Error 2-184
024-370 Marker Code Detection Error 2-185
024-371 The communication between the ESS and IOT has not been established,
which is detected by the Controller.
2-186
Error Message and Chain Link Code Display (Continued)
Chain Link Control Panel Message Go to Page

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
