Parameter Value
Input Type 24 VDC 5 VDC / Differential
Sinus 1 Vpp
Input current per channel
Input voltage +24 V Typ. 14 mA
Input voltage +5 V > 4.8 mA
Input voltage +15 V > 12 mA
Input voltage +30 V < 15 mA
Input type acc. to EN 61131-2 Type 1
Input frequency max. (fast counter) 300 kHz 300 kHz
Input frequency max. (frequency measurement) 5 kHz 5 kHz
Input signal voltage 24 VDC 5 VDC
Signal 0 -3 V...+5 V -3 V...+0,5 V
Undefined signal > +5 V...< +15 V --
Signal 1 +15 V...+30 V +0,5 V...+30 V
Ripple with signal 0 Within -3 V ... +5 V Within -3 V...+0.5 V
Ripple with signal 1 Within +15 V...+30
V
Within +0,5 V...+30
V
Max. cable length
Shielded 1000 m
Unshielded 600 m
Parameter Value
Number of channels 2
Reference potential for all outputs Terminals 1.9...4.9 (negative pole of the process
supply voltage, signal name ZP)
Common power supply voltage For all outputs: terminals 1.8...4.8 (positive pole
of the process supply voltage, signal name UP)
Indication of the output signals Brightness of the LED depends on the number
of pulses emitted (0 % to 100 %) (pulse output
mode only)
Output voltage for signal 1 UP (-0.1 V)
Output voltage for signal 0 ZP (+0.3 V)
Output delay (0->1 or 1->0) Typ. 1 µs
Output current
Rated value, per channel 100 mA at UP = 24 V
Maximum value (all channels together,
configurable outputs included))
8 A
Leakage current with signal 0 < 0.5 mA
Rated protection fuse on UP 10 A fast
De-magnetization when inductive loads are
switched off
With varistors integrated in the module (see
figure above)
Technical Data
of the Fast Out-
puts O0 and O1
2019/04/173ADR010121, 13, en_US672
