Name Value Internal value Internal value,
type
Default
Output 0, Substi-
tute value
Table Substitute
value
Ä Table 146 “Su
bstitute Value”
on page 901
Table Substitute
value
Ä Table 146 “Su
bstitute Value”
on page 901
WORD 0
Output 1,
Channel configu-
ration
Table Operating
modes of the
analog outputs
Ä Table 144 “Ch
annel Configura-
tion”
on page 901
Table Operating
modes of the
analog outputs
Ä Table 144 “Ch
annel Configura-
tion”
on page 901
BYTE 0
Output 1, Check
channel
Table Channel
monitoring
Ä Table 145 “Ch
annel Monitoring”
on page 901
Table Channel
monitoring
Ä Table 145 “Ch
annel Monitoring”
on page 901
BYTE 0
Output 1, Substi-
tute value
Table Substitute
value
Ä Table 146 “Su
bstitute Value”
on page 901
Table Substitute
value
Ä Table 146 “Su
bstitute Value”
on page 901
WORD 0
Table 144: Channel Configuration
Internal value Operating modes of the analog outputs, individually configu-
rable
0 (default) Not used
128 -10 V...+10 V
129 0...20 mA
130 4...20 mA
Table 145: Channel Monitoring
Internal value Check channel
0 Plausib(ility), cut wire, short circuit
3 None
Table 146: Substitute Value
Intended behaviour of
output channel when the
control system stops
Required setting of the
module parameter "Behav-
iour of outputs in case of a
communication error"
Required setting of the
channel parameter "Substi-
tute value"
Output OFF Off 0
Last value infinite Last value 0
Last value for 5 s and then
turn off
Last value 5 sec 0
Last value for 10 s and then
turn off
Last value 10 sec 0
Substitute value infinite Substitute value Depending on configuration
