6-4
Cisco ONS 15454 Procedure Guide, R5.0
August 2005
Chapter 6 Create Circuits and VT Tunnels
NTP-A127 Verify Network Turn Up
Table 6-3 shows the shows the circuit source and destination options for STS circuits.
NTP-A127 Verify Network Turn Up
All OC-192 cards — 192 28 per STS —
FC_MC-4 4 — — —
Table 6-2 CTC Circuit Source and Destination Options for VT Circuits (continued)
Card Ports STSs VTs DS-1s
Table 6-3 CTC Circuit Source and Destination Options for STS Circuits
Card Ports STSs
DS1-14, DS1N-14
1
1. You can route one STS circuit on a DS1 card to carry all 14 ports within the STS. However, 14 VT1.5s are not utilized.
——
DS3-12, DS3N-12, DS3-12E, DS3N-12E 12 —
DS3XM-6 6 —
DS3XM-12 12, or 6 to 12 “portless”
2
2. The number of “portless” interfaces depends on the system configuration. For XC and XCVT drop slots, a maximum
of 6 portless transmultiplexing interfaces are supported. For XC and XCVT trunk slots and XC10G any slot, a
maximum of 12 portless transmultiplexing interfaces are supported.
—
DS3i-N-12 12 1 per port
DS3/EC1-48 48 1 per port
EC1-12 12 —
OC3 IR 4/STM1 4 3 per port
OC3-8 8 3 per port
OC12 IR/STM4 SH 1310
OC12 LR/STM4 LH 1310
OC12 LR/STM4 LH 1550
—12
OC12 IR/STM4 SH 1310-4 4 12 per port
All OC-48 cards (includes ML-Series card) — 48
All OC-192 cards — 192
FC_MC-4 4 —
Purpose This procedure verifies that the ONS 15454 network is ready for circuit
provisioning.
Tools/Equipment None
Prerequisite Procedures Chapter 5, “Turn Up Network”
Required/As Needed Required
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
