Chapter 6 Create Circuits and VT Tunnels
NTP-A147 Create a G-Series STS Circuit
Step 11 Provision the circuit source:
a. From the Node drop-down list, choose the circuit source node. Either end node can be the
point-to-point circuit source.
b. From the Slot drop-down list, choose the slot containing the G-Series card that you will use for one
end of the point-to-point circuit.
c. From the Port drop-down list, choose a port.
Step 12 Click Next.
Step 13 Provision the circuit destination:
a. From the Node drop-down list, choose the circuit destination node.
b. From the Slot drop-down list, choose the slot containing the card that you will use for other end of
the point-to-point circuit.
c. From the Port drop-down list, choose a port.
Step 14 Click Next.
Step 15 In the left pane of the Circuit Routing Preferences panel, confirm that the following information is
correct:
• Circuit name
• Circuit type
• Circuit size
• ONS nodes
Step 16 If the information is not correct, click the Back button and repeat Steps 6 through 15 with the correct
information. If the information is correct, check Route Automatically.
Step 17 Leave all other boxes in the Circuit Routing Preferences panel at the defaults, unless your site plan
dictates otherwise.
Step 18 Click Finish.
Note To change the capacity of a G-Series circuit, you must delete the original circuit and reprovision
a new larger circuit.
Step 19 Complete the “NTP-A149 Test G-Series Circuits” procedure on page 6-81.
Stop. You have completed this procedure.
