Cisco ONS 15454 Series User Manual

17-30
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 17 DLPs A1 to A99
DLP-A24 Install DS-1 AMP Champ Cables on the AMP Champ EIA
Table 17-5 shows the pin assignments for the AMP Champ connectors on the ONS 15454 AMP Champ
EIA for a shielded DS-1 cable.
Table 17-4 Pin Assignments for AMP Champ Connectors
Signal/Wire Pin Pin Signal/Wire Signal/Wire Pin Pin Signal/Wire
Tx Tip 1
white/blue
1 33 Tx Ring 1
blue/white
Rx Tip 1
yellow/orange
17 49 Rx Ring 1
orange/yellow
Tx Tip 2
white/orange
2 34 Tx Ring 2
orange/white
Rx Tip 2
yellow/green
18 50 Rx Ring 2
green/yellow
Tx Tip 3
white/green
3 35 Tx Ring 3
green/white
Rx Tip 3
yellow/brown
19 51 Rx Ring 3
brown/yellow
Tx Tip 4
white/brown
4 36 Tx Ring 4
brown/white
Rx Tip 4
yellow/slate
20 52 Rx Ring 4
slate/yellow
Tx Tip 5
white/slate
5 37 Tx Ring 5
slate/white
Rx Tip 5
violet/blue
21 53 Rx Ring 5
blue/violet
Tx Tip 6
red/blue
6 38 Tx Ring 6
blue/red
Rx Tip 6
violet/orange
22 54 Rx Ring 6
orange/violet
Tx Tip 7
red/orange
7 39 Tx Ring 7
orange/red
Rx Tip 7
violet/green
23 55 Rx Ring 7
green/violet
Tx Tip 8
red/green
8 40 Tx Ring 8
green/red
Rx Tip 8
violet/brown
24 56 Rx Ring 8
brown/violet
Tx Tip 9
red/brown
9 41 Tx Ring 9
brown/red
Rx Tip 9
violet/slate
25 57 Rx Ring 9
slate/violet
Tx Tip 10
red/slate
10 42 Tx Ring 10
slate/red
Rx Tip 10
1
white/blue
1. Pins 26, 27, 28, 29, 30, 58, 59, 60, 61, and 62 correspond to the white/orange binder group. A binder group is a set of 25 pairs
of wires coded with an industry-standard color scheme.
26 58 Rx Ring 10
blue/white
Tx Tip 11
black/blue
11 43 Tx Ring 11
blue/black
Rx Tip 11
white/orange
27 59 Rx Ring 11
orange/white
Tx Tip 12
black/orange
12 44 Tx Ring 12
orange/black
Rx Tip 12
white/green
28 60 Rx Ring 12
green/white
Tx Tip 13
black/green
13 45 Tx Ring 13
green/black
Rx Tip 13
white/brown
29 61 Rx Ring 13
brown/white
Tx Tip 14
black/brown
14 46 Tx Ring 14
brown/black
Rx Tip 14
white/slate
30 62 Rx Ring 14
slate/white
Tx Spare0+
Not applicable
15 47 Tx Spare0–
Not applicable
Rx Spare0+
Not applicable
31 63 Rx Spare0–
Not applicable
Tx Spare1+
Not applicable
16 48 Tx Spare1–
Not applicable
Rx Spare1+
Not applicable
32 64 Rx Spare1–
Not applicable
