17-31
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 17 DLPs A1 to A99
DLP-A24 Install DS-1 AMP Champ Cables on the AMP Champ EIA
Step 4 Return to your originating procedure (NTP).
Table 17-5 Pin Assignments for AMP Champ Connectors (Shielded DS1 Cable)
64-Pin Blue Bundle 64-Pin Orange Bundle
Signal/Wire Pin Pin Signal/Wire Signal/Wire Pin Pin Signal/Wire
Tx Tip 1
white/blue
1 33 Tx Ring 1
blue/white
Rx Tip 1
white/blue
17 49 Rx Ring 1
blue/white
Tx Tip 2
white/orange
2 34 Tx Ring 2
orange/white
Rx Tip 2
white/orange
18 50 Rx Ring 2
orange/white
Tx Tip 3
white/green
3 35 Tx Ring 3
green/white
Rx Tip 3
white/green
19 51 Rx Ring 3
green/white
Tx Tip 4
white/brown
4 36 Tx Ring 4
brown/white
Rx Tip 4
white/brown
20 52 Rx Ring 4
brown/white
Tx Tip 5
white/slate
5 37 Tx Ring 5
slate/white
Rx Tip 5
white/slate
21 53 Rx Ring 5
slate/white
Tx Tip 6
red/blue
6 38 Tx Ring 6
blue/red
Rx Tip 6
red/blue
22 54 Rx Ring 6
blue/red
Tx Tip 7
red/orange
7 39 Tx Ring 7
orange/red
Rx Tip 7
red/orange
23 55 Rx Ring 7
orange/red
Tx Tip 8
red/green
8 40 Tx Ring 8
green/red
Rx Tip 8
red/green
24 56 Rx Ring 8
green/red
Tx Tip 9
red/brown
9 41 Tx Ring 9
brown/red
Rx Tip 9
red/brown
25 57 Rx Ring 9
brown/red
Tx Tip 10
red/slate
10 42 Tx Ring 10
slate/red
Rx Tip 10
red/slate
26 58 Rx Ring 10
slate/red
Tx Tip 11
black/blue
11 43 Tx Ring 11
blue/black
Rx Tip 11
black/blue
27 59 Rx Ring 11
blue/black
Tx Tip 12
black/orange
12 44 Tx Ring 12
orange/black
Rx Tip 12
black/orange
28 60 Rx Ring 12
orange/black
Tx Tip 13
black/green
13 45 Tx Ring 13
green/black
Rx Tip 13
black/green
29 61 Rx Ring 13
green/black
Tx Tip 14
black/brown
14 46 Tx Ring 14
brown/black
Rx Tip 14
black/brown
30 62 Rx Ring 14
brown/black
Tx Tip 15
black/slate
15 47 Tx Tip 15
slate/black
Rx Tip 15
black/slate
31 63 Rx Tip 15
slate/black
Tx Tip 16
yellow/blue
16 48 Tx Tip 16
blue/yellow
Rx Tip 16
yellow/blue
32 64 Rx Tip 16
blue/yellow
To Next Page
