Cisco ONS 15454 Procedure Guide, R5.0
March 2007
Chapter 18 DLPs A100 to A199
DLP-A165 Change Line and Threshold Settings for the DS1-14 or DS1N-14 Cards
Step 6 Repeat Steps 3 through 5 for each subtab that has parameters you want to provision.
Table 18-3 describes the values on the Provisioning > Line tabs for the DS-1 cards.
Table 18-3 Line Options for DS1-14 and DS1N-14 Cards
Parameter Description Options
Port # (Display only.) Sets the port
number.
1 to 14
Port Name Sets the port name. User-defined, up to 32 alphanumeric/special characters.
Blank by default.
See the “DLP-A314 Assign a Name to a Port” task on
page 20-8.
SF BER Sets the signal fail bit error
rate.
• 1E-3
• 1E-4
• 1E-5
SD BER Sets the signal degrade bit
error rate.
• 1E-5
• 1E-6
• 1E-7
• 1E-8
• 1E-9
Line Type Defines the line framing type.
• D4
• ESF - Extended Super Frame
• Unframed
Line Coding Defines the DS-1
transmission coding type.
• AMI - Alternate Mark Inversion (default)
• B8ZS - Bipolar 8 Zero Substitution
Line Length Defines the distance (in feet)
from the backplane
connection to the next
termination point.
• 0 - 131
• 132 - 262
• 263 - 393
• 394 - 524
• 525 - 655
Admin State Sets the port service state
unless network conditions
prevent the change.
• IS—Puts the port in-service. The port service state
changes to IS-NR.
• IS,AINS—Puts the port in automatic in-service.
The port service state changes to OOS-AU,AINS.
• OOS,DSBLD—Removes the port from service and
disables it. The port service state changes to
OOS-MA,DSBLD.
• OOS,MT—Removes the port from service for
maintenance. The port service state changes to
OOS-MA,MT.
