A-6
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Appendix A CTC Information and Shortcuts
Manage the CTC Window
View Go To Previous View Displays the previous CTC view.
Go To Next View Displays the next CTC view. Available only after you navigate to a previous
view. Go to Previous View and Go to Next View are similar to forward and
backward navigation in a web browser.
Go To Parent View References the CTC view hierarchy: network view, node view, and card view. In
card view, this command displays the node view; in node view, the command
displays network view. Not available in network view.
Go To Selected
Object View
Displays the object selected in the CTC window.
Go To Home View Displays the login node in node view.
Go To Network View Displays the network view.
Go To Other Node Displays a dialog box allowing you to type in the node name or IP address of a
a network node that you want to view.
Show Status Bar — Click this item to display or hide the status bar at the bottom of the CTC window.
Show Tool Bar — Click this item to display or hide the CTC toolbar.
— — Zooms out the network view area (toolbar only).
— — Zooms in the network view area (toolbar only).
— — Zooms in a selected network view area (toolbar only).
Table A-3 CTC Menu and Toolbar Options (continued)
Menu Menu Option Toolbar Description
