AKD User Guide | 17 Faults and Warnings
Error Code Fault/Warning
Code
Description
0x8684 123 Warning: Motion global warning
0x7786 301 Warning: Motor overheated.
0x4380 234 Warning: Control temperature sensor 1 high
0x4387 235 Warning: Power temperature sensor 1 high.
0x4382 236 Warning: Power temperature sensor 2 high.
0x4393 237 Warning: Power temperature sensor 3 high.
0x4394 240 Warning: Control temperature sensor 1 low.
0x4385 241 Warning: Control temperature sensor 1 low.
0x4396 242 Warning: Power temperature sensor 2 low.
0x4392 243 Warning: Power temperature sensor 3 low.
0x3280 502 Warning: Bus under voltage.
0x3780 503 Warning: Input phase loss.
0x3287 521 Warning: Dynamic Braking I
2
T.
0x8787 125 Warning: Fieldbus PLL unlocked.
222 Kollmorgen | December 2010
