Request

Function Code 1 Byte 0x03

Starting Address 2 Bytes

0x0000-0xFFFF (see 23 Modbus Parameter

Table)

Quantity of Reg-

isters

2 Bytes Two 32-bit values or four 64-bit values

Normal Response

Function

Code

1 Byte 0x03

Byte Count 1 Byte 2 x N*

Value

N* x 2 Bytes Data

*N = Quantity of Registers

Error Response

Function Code 1 Byte 0x83

Exception

Code

1 Byte

See Exception Response

Codes

Following is an example of reading the position loop feedback PL.FB at index 588 (0x024C), with an actual value

of 0x1 2A05 F200.

Request

Function 03

Starting Address Hi 02

Starting Address Lo 4C

Quantity of Registers Hi 00

Quantity of Registers

Response

Function 03

Byte Count 08

AKD User Guide | 22 Modbus

Kollmorgen | December 2010 71
