6-6
Cisco ONS 15454 Procedure Guide, R5.0
August 2005
Chapter 6 Create Circuits and VT Tunnels
NTP-A181 Create an Automatically Routed DS-1 Circuit
f. Click the Security tab. Verify that the users and access levels are provisioned as specified. If not,
see the “NTP-A30 Create Users and Assign Security” procedure on page 4-4 to correct the
information.
g. If Simple Network Management Protocol (SNMP) is used, click the SNMP tab and verify the trap
and destination information. If the information is not correct, see the “NTP-A87 Change SNMP
Settings” procedure on page 10-6 to correct the information.
h. Click the Comm Channels tab. Verify that DCCs were created to the applicable OC-N slots and
ports (time-division multiplexing [TDM] nodes) or Optical Service Channel (OSC) slots and ports
(DWDM nodes). If DCCs were not created for the appropriate OC-N or OSC slots and ports, see
Chapter 5, “Turn Up Network” and complete the turn-up procedure appropriate for your network
topology.
i. Click the Timing tab. Verify that timing is provisioned as specified. If not, use the “NTP-A85
Change Node Timing” procedure on page 10-5 to make the changes.
j. Click the Alarm Profiles tab. If you provisioned optional alarm profiles, verify that the alarms are
provisioned as specified. If not, see the “NTP-A71 Create, Download, and Assign Alarm Severity
Profiles” procedure on page 7-7 to change the information.
k. Verify that the network element defaults listed in the status area of the node view window are
correct.
Step 7 Repeat Step 6 for each node in the network.
Step 8 Complete the appropriate circuit creation procedure from the NTP list in the “Before You Begin” section
on page 6-1.
Stop. You have completed this procedure.
NTP-A181 Create an Automatically Routed DS-1 Circuit
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at the node where you will create the circuit.
If you are already logged in, continue with Step 2.
Step 2 If you want to assign a name to the circuit source and destination ports before you create the circuit,
complete the “DLP-A314 Assign a Name to a Port” task on page 20-8. If not, continue with Step 3.
Step 3 From the View menu, choose Go to Network View.
Step 4 Click the Circuits tab, then click Create.
Step 5 In the Circuit Creation dialog box, complete the following fields:
Purpose This procedure creates an automatically routed DS-1 circuit, meaning that
CTC chooses the circuit route based on the parameters you specify and on
the software version.
Tools/Equipment None
Prerequisite Procedures NTP-A127 Verify Network Turn Up, page 6-4
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
