6-43
Cisco ONS 15454 Procedure Guide, R5.0
August 2005
Chapter 6 Create Circuits and VT Tunnels
NTP-A295 Create a Manually Routed OC-N Circuit
• If you entered more than 1 in the number of Circuits field and did not choose Auto-ranged, the
Circuit Creation dialog box appears so you can create the remaining circuits. Repeat
Steps 5 through 19 for each additional circuit. After completing the circuits, the Circuits window
appears.
Step 21 In the Circuits window, verify that the circuits you created appear in the circuits list.
Step 22 Complete the “NTP-A62 Test OC-N Circuits” procedure on page 6-51. Skip this step if you built a test
circuit.
Stop. You have completed this procedure.
NTP-A295 Create a Manually Routed OC-N Circuit
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at the node where you will create the circuit.
If you are already logged in, continue with Step 2.
Step 2 If you want to assign a name to the tunnel source and destination ports before you create the circuit,
complete the “DLP-A314 Assign a Name to a Port” task on page 20-8. If not, continue with Step 3.
Step 3 From the View menu, choose Go to Network View.
Step 4 Click the Circuits tab, then click Create.
Step 5 In the Circuit Creation dialog box, complete the following fields:
• Circuit Type—Choose STS.
• Number of Circuits—Enter the number of OC-N circuits you want to create. The default is 1.
• Auto-ranged—Applies to automatically routed circuits only. If you entered more than 1 in the
Number of Circuits field, uncheck this box. (The box is unavailable if only one circuit is entered in
Number of Circuits.)
Step 6 Click Next.
Step 7 Define circuit attributes:
• Name—Assign a name to the circuit. The name can be alphanumeric and up to 48 characters
(including spaces). Circuit names should be 44 characters or less if you want the ability to create
monitor circuits. If you leave the field blank, CTC assigns a default name to the circuit.
• Size—Choose the OC-N circuit size. Choices are STS-1, STS-3c, STS-6c, STS-9c, STS-12c,
STS-18c, STS-24c, STS-36c, STS-48c, or STS-192c.
• Bidirectional—Leave checked for this circuit (default).
Purpose This procedure creates a manually routed, bidirectional or unidirectional,
OC-N circuit, including STS-1 or concatenated STS-3c, STS-6c, STS-9c,
STS-12c, STS-24c, STS-48c, or STS-192c speeds.
Tools/Equipment None
Prerequisite Procedures NTP-A127 Verify Network Turn Up, page 6-4
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
