18-47
Cisco ONS 15454 Procedure Guide, R5.0
March 2007
Chapter 18 DLPs A100 to A199
DLP-A169 Change Line and Threshold Settings for the EC1-12 Card
Table 18-20 lists the SONET Threshold options for EC1-12 cards.
Service State Identifies the autonomously
generated state that gives the
overall condition of the port.
Service states appear in the format:
Primary State-Primary State
Qualifier, Secondary State.
• IS-NR—(In-Service and Normal) The port
is fully operational and performing as
provisioned.
• OOS-AU,AINS—(Out-Of-Service and
Autonomous, Automatic In-Service) The
port is out-of-service, but traffic is carried.
Alarm reporting is suppressed. The ONS
node monitors the ports for an error-free
signal. After an error-free signal is detected,
the port stays in OOS-AU,AINS state for
the duration of the soak period. After the
soak period ends, the port service state
changes to IS-NR.
• OOS-MA,DSBLD—(Out-of-Service and
Management, Disabled) The port is
out-of-service and unable to carry traffic.
• OOS-MA,MT—(Out-of-Service and
Management, Maintenance) The port is
out-of-service for maintenance. Alarm
reporting is suppressed, but traffic is carried
and loopbacks are allowed.
AINS Soak Sets the automatic in-service soak
period.
• Duration of valid input signal, in hh.mm
format, after which the card becomes in
service (IS) automatically
• 0 to 48 hours, 15-minute increments
Table 18-19 Line Options for the EC1-12 Card (continued)
Parameter Description Options
Table 18-20 SONET Threshold Options for the EC1-12 Card
SONET
Layer Parameter Description Options
All Port # (Display only.) EC-1 card
port #
1 to 12
Line (L) CV Coding violations Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Refresh.
ES Errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Refresh.
SES Severely errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Refresh.
