2-436 MACHINE OPERATIONS OPERACIONES DE MECANIZADO
In actual cutting, tool nose radius must be taken
into consideration (Tool nose radius: 0.8 mm).
The program using the manual tool nose radius
offset function is shown below.
NOT A
En el corte real, deberá tener en consideración el radio
de la nariz de la herramienta (Radio de la nariz de la
herramienta: 0,8 mm).
A continuación se presenta el programa que utiliza la
función de corrección manual del radio de la nariz de
la herramienta.
O1;
N1; N2;
G50 S2000; G50 S2000;
G00 T0101; G00 T0202;
G96 S120 M03; G96 S180 M03;
X68.0 Z20.0 M08; X34.0 Z20.0;
G01 Z0.1 F1.0; G01 Z0 F1.0;
X10.0 F0.2; X−1.6 F0.15;
X−1.6 F0.1; G00 X25.06 Z1.0;
G00 X52.0 Z1.0; G01 X30.0 Z−1.47 F0.2;
G01 Z−49.9 F0.25; Z−20.0;
G00 U2.0 Z1.0; X43.779;
X44.0; X50.0 Z−40.740;
G01 Z−19.9; Z−50.0;
G00 U2.0 Z1.0; X57.06;
X36.0; X62.0 Z−52.47;
G01 Z−19.9; G00 U1.0 Z20.0 M09;
G00 U2.0 Z1.0; X100.0 Z100.0 M05;
X26.3; M30;
G01 X30.3 Z−1.0;
Z−19.9;
X44.3;
X50.3 Z−39.9;
Z−49.9;
X58.3;
X62.3 Z−51.9;
G00 U1.0 Z20.0;
X100.0 Z100.0;
M01;
Part program for rough
cutting
Programa de pieza para
corte en desbaste
Part program for finishing
Programa de pieza para
acabado
