2-497MACHINE OPERATIONS OPERACIONES DE MECANIZADO
26-3 Checking Set Positions
Comprobación de las posiciones establecidas
Before operating the in machine running type work
unloader, confirm that the set positions are appropri-
ate by single operation.
Antes de poner en funcionamiento el descargador de piezas
de tipo integrado, asegúrese de que las posiciones
establecidas son correctas mediante una operación única
26-3-1 Procedure for Checking Set Positions
Procedimiento para comprobar las posiciones establecidas
1) Press [SYNCHRO. ON/OFF] to turn the
synchronous mode OFF.
2) Confirm the operation starting condition for single
operation.
3) Input an item number displayed on the screen
(INPUT) key [EXECUTE].
4) Confirm that the work unloader stops at the set
position.
1) Pulse [SINCRON. ACT/DESA] para DESACTIVAR el
modo sincronizado.
2) Confirme el estado de inicio del funcionamiento para
llevar a cabo la operación única.
3) Introduzca un número de apartado visualizado en la
pantalla tecla (INPUT) [EJEC.]
4) Confirme que el descargador de piezas se detiene en la
posición de ajuste.
26-3-2 Starting Condition List for Single Operation
Lista de condiciones para el inicio de funcionamiento durante la función de operación única
Perform single operation in the manual mode
while the operation selection key-switch is
placed at the [Operation & Edit Enable]
position.
NOT A
Ejecución de la operación única en modo manual con
la llave del interruptor de selección colocada en la
posición [Operación y edición activadas].
"Starting Condition List for Single Oper-
ation" (page 2-497)
"Lista de condiciones para el inicio de funciona-
miento durante la función de operación única"
(página 2-497)
Operation
Operating Start Condition
Hand Receiver
1. Standby position
Arm up Arm up
2. Work eject position
Arm up Arm up and receiver home position
3. Arm down position (main)
Arm up Arm up
4. Arm down position (sub)
Arm up Arm up
5. Work clamp position (main)/
Work receipt position (main)
Arm down and hand open Arm down
6. Work clamp position (sub)/
Work receipt position (sub)
Arm down and hand open Arm down
7. Return position (main)
Main chuck open or hand open Without condition
8. Return position (sub)
Sub chuck open or hand open Without condition
9. Arm down
Hand open and arm down (or return)
position
Arm down or return position
10. Arm up
Hand open or except workpiece
clamp position
Except workpiece clamp position
11. Hand open
Without condition
12. Hand close
Without condition
13. Work receiver rotation
Without condition
14. Work receiver zero point
Without condition
