2-621MACHINE OPERATIONS OPERACIONES DE MECANIZADO
29-7 Lubricating Unit Alarms
Alarmas concernientes a la unidad de lubricación
29-7-1 EX0562 (LUBRICANT PRESSURE LOW)
EX0562 (LUBRICANT PRESSURE LOW) (PRESIÓN BAJA DEL REFRIGERANTE)
Lubricating unit abnormal pressure
alarm triggered.
Appropriate Lubricant Viscosity
Change to lubricant
with appropriate viscosity.
"Lubricating Unit" (page
2-562)
Confirm if generated
in either lubricating unit or piping.
Disconnect piping from lubrication
unit tank and check lubricating unit
For the mounting position of
the lubricating unit, refer to
"Maintenance Route Map"
(page 2-515).
Pressure does not rise Pressure rises (normal)
No
Yes
Alarm generated
by lubricating unit malfunction.
Suction Filter Cleaning/Replacement
"Cleaning Lubricant Tank,
Suction Filter and Fill Port
Filter" (page 2-564)
Disassembling/Cleaning/
Adjusting Relief Valve
"Lubricating Unit Relief
Valve Disassembly/
Cleaning" (page 2-624),
"Lubricating Unit Relief
Valve Adjustment" (page
2-625)
Pump Malfunction
Alarm generated
by relief valve malfunction.
No Recovery
Contact the Mori Seiki Service
Department for assistance.
Air Removal
"Lubricating Unit Air
Removal" (page 2-623)
Alarm generated
by piping malfunction.
Lubricant Leakage Check
"Lubricating Unit Lubri-
cant Leakage Check"
(page 2-626)
No Recovery
No Recovery
Recovery
Recovery Recovery
Recovery
Recovery
No Recovery
