2-547MACHINE OPERATIONS OPERACIONES DE MECANIZADO
(Q40058 002)
1. The asterisk indicates the zero position.
2. MC: NL1500MC, NL1500Y,
NL1500SMC, NL1500SY,
NL2000MC, NL2000Y,
NL2000SMC, NL2000SY Specifi-
cations Only
S: NL1500S, NL1500SMC,
NL1500SY, NL2000S,
NL2000SMC, NL2000SY
Specifications Only
SMC: NL1500SMC, NL1500SY,
NL2000SMC, NL2000SY
Specifications Only
Y: NL1500Y, NL1500SY, NL2000Y,
NL2000SY Specifications Only
NOT A
1. Un asterisco indica la posición cero.
2. MC: Especificaciones exclusivas NL1500MC,
NL1500Y, NL1500SMC, NL1500SY,
NL2000MC, NL2000Y, NL2000SMC,
NL2000SY
S: Especificaciones exclusivas de los
modelos NL1500S, NL1500SMC,
NL1500SY, NL2000S, NL2000SMC,
NL2000SY
SMC: Especificaciones exclusivas de los
modelos NL1500SMC, NL1500SY,
NL2000SMC, NL2000SY
Y: Especificaciones exclusivas de los
modelos NL1500Y, NL1500SY, NL2000Y,
NL2000SY
No.
N°
Symbol
Símbolo
Order No.
N° de pedido
Parts Name
Designación de la pieza
Q'ty
Ctd.
Maker
Fabricante
1 * U00535A Oil Tank 10 L 1 DAIKIN
2 * * Suction Strainer DHA-06-150 1 DAIKIN
3 * * Oil level Gage KLA-80A 1 DAIKIN
4 * Inverter Pump * 1 DAIKIN
5 * * Air Breather & Oil Gage HY-06T 1 DAIKIN
6 * * Oil Cooler 1734294-01 1 DAIKIN
7 * Controller EUH14-L04-A-30-133 1 DAIKIN
8 * U00536A Manifold BT-202-50-S 1 DAIKIN
9 * U00536A Manifold BT-202-50-S 1 DAIKIN
10 * * A Port Pilot Controlled Check Valve MP-02A-20-55 1 DAIKIN
11 YV80, YV81 * Solenoid Controlled Valve KSO-G02-2DA-30-E 1 DAIKIN
12 * * Orifice φ2.1 (K02-021) 1 DAIKIN
13 * * P Port Check Valve MC-02P-05-65 1 DAIKIN
14 YV171 * Solenoid Controlled Valve KSO-G02-2BA-30-E 1 DAIKIN
15 * U00532A Manifold BT-102-50-S (UK4273-1) 1 DAIKIN
16 * U00530B Manifold BT-202-50-S (UK4276-1) 1 DAIKIN
17 * * P Port Pressure Reducing Valve MG-02P-03-55-T-74 1 DAIKIN
18 * * Gage Block Y4322963 1 DAIKIN
19 YV10, YV11 * Solenoid Controlled Valve KSO-G02-2DA-30-E 1 DAIKIN
20 * * Pressure Gage YSPA1/4R × φ60 × 6 MPa (PS0779-SN) 1 DAIKIN
21 * * P Port Pressure Reducing Valve MG-02P-03-55-T-74 1 DAIKIN
22 * * Gage Block Y4322963 1 DAIKIN
23
YV120,
YV121
* Solenoid Controlled Valve KSO-G02-2DA-30-E 1 DAIKIN
24 * * Pressure Gage YSPA1/4R × φ60 × 6 MPa (PS0779-SN) 1 DAIKIN
25 * P27323A High Pressure Hydraulic Hose NWP70 9*320 (3/8) 1
OSAKA
KOUATSU
