2-560 MACHINE OPERATIONS OPERACIONES DE MECANIZADO
(Q40088 001)
No.
N°
Symbol
Símbolo
Drawing No.
N° de ilustra-
ción
Name
Designación
Model
Modelo
Q'ty
Ctd.
Maker
Fabricante
1 * U00531B Oil Tank 10L 1 DAIKIN
2 * * Suction Strainer DHA-06-150 1 DAIKIN
3 * * Oil Level Gauge KLA-80A 1 DAIKIN
4 * * Inverter Pump * 1 DAIKIN
5 * * Air Breather & Oil Gage HY-06T 1 DAIKIN
6 * * Oil Cooler 1734294-01 1 DAIKIN
7 * * Controller EUH25-L04-A-3D-127 1 DAIKIN
8 * U00536A Manifold BT-202-50-S (UK4619) 1 DAIKIN
9 * *
A Port Pilot Controlled Check
Valve
MP-02A-20-55 1 DAIKIN
10 YV80, YV81 * Solenoid Controlled Valve KSO-G02-2DA-30-E 1 DAIKIN
11 * * Orifice φ2.1 (K02-021) 1 DAIKIN
12 * U00532A Manifold BT-102-50-S (UK4273-1) 1 DAIKIN
13 * U00533A Manifold BT-202-50-S (UK4276-1) 1 DAIKIN
14 * *
P Port Pressure Reducing
Valve
MG-02P-03-55-T-74 1 DAIKIN
15 * * Gauge Block Y4322963 1 DAIKIN
16 YV10, YV11 * Solenoid Controlled Valve KSO-G02-2DA-30-E 1 DAIKIN
17 * * Pressure Gauge
YSPA1/4R × φ60 × 6 MPa
(PS0779-SN)
1 DAIKIN
18 * * P Port Check Valve MC-02P-05-65 1 DAIKIN
19 YV171 * Solenoid Controlled Valve KSO-G02-2BA-30-E 1 DAIKIN
20 * U00526A Manifold BT-202-50-S 1 DAIKIN
21 * * T Port Check Valve MC-02T-05-65 1 DAIKIN
22 * *
P Port Pressure Reducing
Valve
MG-02P-03-55-T-74 1 DAIKIN
23 * * Gauge Block BG-02PT-55 1 DAIKIN
24 YV20, YV21 * Solenoid Controlled Valve KSO-G02-2BA-30-E 1 DAIKIN
25 * * Pressure Gauge
YSPA1/4R × φ60 × 6 MPa
(PS0779-SN)
1 DAIKIN
26 * * P Port Check Valve MC-02P-05-65 1 DAIKIN
27 YV31 * Solenoid Controlled Valve KSO-G02-2BA-30-E 1 DAIKIN
28 * B13283A Block Joint * 1 *
29 * B12150A Block Joint * 1 *
30 * P27713A
High Pressure Hydraulic
Hose
NWP70 9*750 (3/8) 1 OOSAKA KOATU
31 * P22598A
High Pressure Hydraulic
Hose
NWP70 12*700 (1/2) 1 OOSAKA KOATU
32 * P27712A
High Pressure Hydraulic
Hose
NWP70 9*3850 (3/8) 1 OOSAKA KOATU
